    CMOS Fixed Barcode Scanner QR 2D Bar Code Scanner For Self Service Vending Machine

    Ask Lasest Price
    Brand Name : YJFIRST
    Model Number : YJ-ES906
    Certification : CE, ROHS, FCC, IEC, FDA
    Price : $17
    Payment Terms : T/T ，D/P，D/A ，L/C ， MoneyGram ，Western Union
    Supply Ability : 20000pcs/month
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    CMOS Fixed Barcode Scanner QR 2D Bar Code Scanner For Self Service Vending Machine

    Embedded 2d Bar Code Scanner Qr Code Scanner Camera Module Qr 2d Barcode Scanner for Self-Service Vending Machines

    Parameter

    Capability
    Collection method
    Image type, CMOS Sensor
    Picking rate
    1 / 60 Seconds
    Field of view Angle
    Horizontal 62°, and 48.5° vertical
    Ability to read
    Identification accuracy
    ≥5mil
    Read the way
    Close to, close to the reading
    Scan depth of field
    test condition
    depth of field
    Code 128 10mil 18bytes Paper copy code
    35~200mm
    Code 128 18bytes Mobile phone code
    35~230mm
    QR 10mil 160bytes Paper copy code
    30~120mm
    DM 15mil 100bytes Paper copy code
    35~180mm
    QR 18bytes Mobile phone code
    30~330mm
    Code 128 10mil 18bytes Paper copy code
    35~200mm
    Scan the Angle
    The rotation angle was 360°, elevation angle ± 55°, and bias angle ± 55°
    Support code system
    In line with the international and domestic general QR code standards:
    QR Code, PDF417, DataMatrix (ECC200), etc
    In line with the international and domestic general one-dimensional code standards:
    EAN 13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSI Plessey, RSS-14, qualified RSS, extended RSS, etc
    Print contrast
    Minimum 25% of the reflection difference
    LED
    Fill-in light
    White
    Physical parameters
    Size
    5*2.4*1.6cm (Long, width and height)
    Weight
    About 9g
    Joggle
    Joggle
    4 PIN cable socket: USB KBW
    4 PIN cable socket: Serial port TTL 232 (5V or 3.3V)
    Scan pattern
    Command mode / induction mode / trigger mode
    Read success tips
    The LED and the buzzer
    Data line (optional)
    4PIN straight line
    Enviromental parameter
    Working temperature
    -20℃ ~ 60℃
    Storage temperature
    -20℃ ~ 70℃
    Humidity
    Relative humidity: 5% ~ 95% (no condensation)
    Ambient light
    Max.100,000 Lux
    Electrical parameters
    Input voltage
    5V or 3.3V
    Working current
    130mA
    Standby current
    87m A
    FAQ
    Q:Can you send sample?
    A:Yes, YJFIRST welcomes sample order to test. Please contact us for more details before placing sample order.
    Q:Can we have our logo or company name to be printed on the product or package?
    A:Yes, printer with logo or company name is acceptable, it will be accomplished by silk printing,please contact us for more details.
    Q:What's the shipping way?
    A: There are DHL, Fedex, TNT, UPS. We also can ship the goods by your shipping account or other express agent you provided.
    Q:What's the payment way?
    A:We accept Alibaba online orders, PayPal ,T T, LC, Westem Union , MoneyGram.
    Q:How about your product warranty?
    A:Our oficiallyy promised warranty time is two years after delivery.
    Q:How is your quality control?
    A:Professional QC team and testing machine( Engine age testing, wire bending machine, switch life testing, shock resistance testing). CE, FCC & ROHS certificated.
    Q:If I come across any problem during product using, where I can get the support?
    A:We support you technically 24h/7. Please send all your questions to us, and we will give the professional, patient, expliantion by email or call in time.
