Access Control RFID NFC QR Code Card Reader RS232 Card Reader for Integrated Embedding
Product introduction
YJ-ES902 is a 2D mini high speed desktop scanner with advanced CMOS image recognition technology.
It can easily read paper, goods, screen and other media 1D 2D barcodes.
Widely used in kiosk, turnstiles, vending machines, ticket checking machines.
Features
Parameter
| Collection capacity | ||
| Method of collection | Imaging, CMOS sensor | |
| picking rate | 1 / 60 second | |
| Field of view Angle | Horizontal 62°, vertical 48.5° | |
| Reading ability | ||
| Recognition accuracy | ≥5mil | |
| Reading methods | Close, close reading | |
| Scan the depth of field | test condition | depth of field |
| Code 128 10mil 18bytes paper code | 35~200mm | |
| Code 128 18bytes mobile code | 35~230mm | |
| QR code 10mil 160bytes paper code | 30~120mm | |
| DM 15mil 100bytes paper code | 35~180mm | |
| QR 18bytes mobile code | 30~380mm | |
| Code 128 10mil 18bytes paper code | 35~200mm | |
| The Angle of view | The corner Angle is 360°, the elevation Angle is ± 55°, and the deviation Angle is ± 55° | |
| Supported coding system | Comply with international and domestic universal QR code standards: QR Code, PDF417, DataMatrix (ECC200), etc Complies with international and domestic universal one-dimensional code standards: EAN13, EAN8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSI Plessey, RSS-14, limited RSS, extended RSS, etc | |
| Print contrast | Minimum 25% reflection difference | |
| LED | ||
| fill-in light | white | |
| Physical parameters | ||
| size (L x W x H) | 54.5mm×34.7mm×17.5mm | |
| weight | Less than 30g | |
| joggle | ||
| jack | Micro USB cable socket | |
Typical Use Cases:
Self-checkout machines | - Assembly line tracking
Smart lockers & vending | - Medical inventory management
Key Advantage: Combines "invisible" scanning with industrial reliability for automated workflows.
FAQ
Q1. Can I get a sample? And how can I get it? How many days will samples be finished?
Yes, samples can be provided , but to be paid by customers. Sample fee will be credit in formal order. Most of samples are
in stock, it takes 3-6 days by express delivery.
Q2. Do you inspect the finished products?
Yes, each step of production and finished products will be carried out inspection by QC department before shipping.
Q3. What advantage do you have?
1. Full rang of barcode scanner products & Independent research and development department,Supply OEM.
2. We are a manufacturer, and it ensures we have the ability to carry out the production schedule for punctual delivery.
3. Strict QC. For each order, strict inspection will be carried out by the QC department before shipping,
4. Certificates: Kinds of Invention Patents & CE&FCC& ROSH&ISO900:2008 and so on;
|
|
